AS 2821-1985 PDF

AS 2821-1985 PDF

Original price was: $90.00.Current price is: $50.00.

Fluid power systems and components – Cylinders – Identification code for mounting dimensions and mounting types
standard by Standards Australia, 01/01/1985

Available Formats: PDF   In Stock

Please note: All product prices are in USD, not AUD.

Category:

NOTE: Our website provide PDF immediately download, sometimes when the payment is processed and you did not receive the file, please do not worry and our customer service will send to you via email within 6 hours.

Description

Adopted from and identical with ISO 6099. It specifies a conventional system for identifying fluid power cylinder dimensions and mounting dimensions. The system is composed of a letter code for identifying mounting dimensions, envelope dimensions, and cylinder fitting dimensions as well as a code for identifying cylinder mounting types. It does not represent a standard list of all cylinder mounting types but it does establish uniform descriptions for dimensions and a conformity of terms. The codes are not complete as allowance is provided for future development.

Product Details

Edition:
1st
Published:
01/01/1985
ISBN(s):
0726238937
Number of Pages:
45
File Size:
1 file , 230 KB
Product Code(s):
10141759, 10141840, 10141808
